| Printing technology | |
| Printhead | EPSON 53200-A1,16 |
| Printing speed | Express Mo 640M²/h |
| Quanlity Mode 220M²/h | |
| Printhead maintain | Automatic cleaning and moisturizing |
| Ink solution | |
| Inktype | Dye sublimation ink,Pigment ink |
| Color scheme | 8 colors |
| Cartridge capacity | 10L/color |
| Ink supply mode | Automatic degassing,automatic negative pressure,ink cirulation |
| Media handling system | |
| Media loading | roll to roll |
| Media dimension | Max.roll diameter 1100mm,Max.weight 1000KG |
| Printing format | Max.2000mm |
| Media format | Max.2050mm |
| Media type | Heat transfer paper,wood grain paper,corrugated paper,film,etc., the minimum weight of 31g |
| Data transfer | |
| Data interface | Optical data communication,USB3.0 |
| Rip software | FLORA,NeoStampa,ONYX,other |
| Dimensions | |
| Machine size | Net size(Lxw×H):4300×1150x2300mm Package size(LxW×H):4450x1050x2350mm |
| Rewinding size | Net slze(Lxw×H):2610×1300×1150mm Package size(LxW×H):2700×1550×1450mm |
| Net weight | Machine is 2100KG,Winding is 500KG |
| Emvironment requirement | |
| Temperature | 25~28℃ |
| Humidity | 60%~70%no-condensing |
| Power&Airpressure requirements | |
| Power | Machine:AC380V±10%50/60HZ 20A Dryer:AC380V±10%50/60HZ 63A |
| Air | clean and dry air 20.6Mpa,0.6M3/min,Air tank2230L |
| Warranty | |
| 12 months(Please contact local distributors for more information.) | |
